Digging depth

2.13 m
7 ft, 0 in.

SAE dipperstick digging force

6681 N
1502 lb

SAE bucket digging force

11,005 N
2474 lb

Swing arc

150 degree (angle)

Boom lift capacity

116 kg
256 lb

Transport height

1.92 m
6 ft, 3 in.

Stabilizers spread width, up

1.47 m
4 ft, 10 in.

Stabilizers spread width, down

1.92 m
6 ft, 7 in.

Bucket widths

203.2 mm (8 in.)
304.8 mm (12 in.)
406.4 mm (16 in.)

Swing arc

150 degree (angle)

Bucket rotation

180 degree (angle)

Boom lift capacity

116 kg
256 lb

SAE dipperstick digging force

6681 N
1502 lb

SAE bucket digging force

11,005 N
2474 lb

Bucket control main relief valve pressure

2370 psi

Digging depth

2.13 m
7 ft, 0 in.

Loading height (bucket at 60 degrees)

1.74 m
6 ft, 1 in.

Reach from center line of swing pivot

3.0 m
9 ft, 9 in.

Transport height

1.92 m
6 ft, 3 in.

Loading reach (bucket at 60 degrees)

1.13 m
3 ft, 7 in.

Transport overhang

1.1 m
3 ft, 6 in.

Undercut

43 cm
17 in.

Stabilizer type

Stabilizers spread width, up
1.47 m
4 ft, 10 in.
Stabilizers spread width, down
1.92 m
6 ft, 7 in.
