Digging depth

103 in.
2.61 m

SAE dipperstick digging force

2449 lb
10893 N

SAE bucket digging force

3752 lb
16689 N

Swing arc

170 degree (angle)

Boom lift capacity

820 lb
372 kg

Transport height

91 in.
2.31 m

Stabilizers spread width, up

62 in.
1.57 m

Stabilizers spread width, down

95 in.
2.41 m

Bucket widths

9 in. (228 mm)
12 in. (305 mm)
16 in. (406 mm)
18 in heavy-duty (457 mm)
20 in. (508 mm)
24 in. (610 mm)

Swing arc

170 degree (angle)

Bucket rotation

180 degree (angle)

Boom lift capacity

820 lb
372 kg

SAE dipperstick digging force

2449 lb
10893 N

SAE bucket digging force

3752 lb
16689 N

Bucket control main relief valve pressure

2250 psi
17580 kPa

Digging depth

103 in.
2.61 m

Loading height (bucket at 60 degrees)

78 in.
1.98 m

Reach from center line of swing pivot

140 in.
3.55 m

Transport height

91 in.
2.31 m

Loading reach (bucket at 60 degrees)

51 in.
1.11 m

Transport overhang

48 in.
1.29 m

Undercut

19 in.
.48 m

Stabilizer type

Stabilizers spread width, up
62 in.
1.57 m
Stabilizers spread width, down
95 in.
2.41 m
