Digging depth

9 ft, 4 in.

SAE dipperstick digging force

3065 lb

SAE bucket digging force

5532 lb

Swing arc

180 degree (angle)

Boom lift capacity

905 lb

Transport height

8 ft
2.6 m
8 in.

Stabilizers spread width, up

5 ft
1.6 m
4 in.

Stabilizers spread width, down

9 ft
2.9 m
8 in.

Bucket widths

14 in.
18 in.
24 in.
36 in.
40 in.

Swing arc

180 degree (angle)

Bucket rotation

180 degree (angle)

Boom lift capacity

905 lb

SAE dipperstick digging force

3065 lb

SAE bucket digging force

5532 lb

Hydraulic relief setting

2400 psi

Digging depth

9 ft, 4 in.

Loading height (bucket at 60 degrees)

8 ft
2.4 m
2 in.

Reach from center line of swing pivot

12 ft
3.9 m
11 in.

Transport height

8 ft
2.6 m
8 in.

Loading reach (bucket at 60 degrees)

5 ft
1.5 m
1 in.

Transport overhang

5 ft
1.5 m
1 in.

Undercut

1 ft
335 mm
10 in.

Stabilizer type

Stabilizers spread width, up
5 ft
1.6 m
4 in.
Stabilizers spread width, down
9 ft
2.9 m
8 in.
Hydraulic
