Boom length options

18.3/27.4, 18.3/30.5, 22/36.6, or 22/40.2 m
60/90, 60/100, 72/120, or 72/132 ft

Automatic boom height

BoomTrac Pro 2 - five sensor (optional)

Plumbing material

Stainless steel
Optional: Polyethylene

Boom Material

Steel or carbon fiber

Ground height adjustment

50 to 245 cm
19.6 to 96.5 in.

Breakaway width

Stainless-steel boom: 3.3 m
10.8 ft
Carbon fiber boom: 3.7 m
12.1 ft

Boom sections

13 sections with boom length: 40.2 m
132 ft
11 sections with boom length: 36.6 m
120 ft
9 sections with boom length: 30.5 m
100 ft
7 sections with boom length: 27.4 m
90 ft

Nozzle spacings

38.1 or 50.8 cm
15 or 20 in.

Type

Hydrostatic

Drive

Full-time four-wheel drive (4WD)

Shifting

Electrohydraulic

Hydraulic reservoir capacity

98 L
26 gal.

Spray speed range

0 to 32.2 km/h
0 to 20 mph

Transport speed, maximum

48.3 km/h
30 mph

Dry compatible

Yes: 5.7 m³
200 cu ft

Suspension

Dual-strut independent wheel air-ride suspension

Crop clearance with standard tires

152 cm
60 in.

Front tires

320/90 R46, 380/90 R46, or 420/80 R46

Rear tires

320/90 R46, 380/90 R46, or 420/80 R46

Flotation tires

520/85R38 or 620/70R38 (field installed only)

Hydraulic tread adjust

Standard

Wheel tread spacing

305 to 406 cm
120 to 160 in.

Wheel base

430 cm
169.3 in.

Turning radius

8.7 m
28.5 ft

Parking brake

Spring-engaged, hydraulically disengaged wet disk pack

Primary brakes

Hydrostatic

Ladder raise/lower

Automatic

Total weight with carbon fiber boom

36.6-m (120-ft) boom: 12,684 kg
27,963 lb
40.2-m (132-ft) boom: 12,739 kg
28,084 lb

Total weight (empty solution tank)

30,328 kg
*Includes: 30.5-m (100-ft) steel boom, pressure recirculation, ExactApply, and 38.1-cm (15-in.) spacing. Weight will vary depending on all options.

Air compressor

Standard: Onboard air

Foam marker capacity

Air injection foamer: 5.7 L
1.5 gal.

Date collected

1-Mar-2021
