Boom length options

27.4, 30.5, 36.6, or 40.2 m
90, 100, 120, or 132 ft

Automatic boom height

BoomTrac Pro 2 - five sensor (optional)

Plumbing material

Stainless steel
Optinal: Polyethylene

Boom Material

Steel or carbon fiber

Ground height adjustment

50 to 245 cm
19.6 to 96.5 in.

Breakaway width

Stainless-steel boom: 3.3 m
10.8 ft
Carbon fiber boom: 3.7 m
12.1 ft

Boom sections

13 sections with boom length: 40.2 m
132 ft
11 sections with boom length: 36.6 m
120 ft
9 sections with boom length: 30.5 m
100 ft
7 sections with boom length: 27.4 m
90 ft

Nozzle spacings

38.1 or 50.8 cm
15 or 20 in.

Type

Hydrostatic

Drive

Full-time four-wheel drive (4WD)

Shifting

Electrohydraulic

Hydraulic reservoir capacity

98.4 L
26 gal.

Spray speed range

0 to 40.2 km/h
0 to 25 mph

Transport speed, maximum

56.3 km/h
35 mph

Dry compatible

Yes: 5.7 m³
200 cu ft

Suspension

Dual-strut independent wheel air-ride suspension

Crop clearance with standard tires

152.4 cm
60 in.

Front tires

320/90 R46, 380/90 R46, or 420/80 R46

Rear tires

320/90 R46, 380/90 R46, or 420/80 R46

Flotation tires

520/85R38 or 620/70R38 (field installed only)

Hydraulic tread adjust

Standard

Wheel tread spacing

305 to 406.4 cm
120 to 160 in.

Wheel base

430 cm
169.3 in.

Turning radius

8.7 m
28.5 ft

Parking brake

Spring-engaged, hydraulic-disengaged wet disk pack

Primary brakes

Hydrostatic

Ladder raise/lower

Automatic

Total weight with carbon fiber boom

36.6-m (120-ft) boom: 13,877.2 kg
30,594 lb
40.2-m (132-ft) boom: 13,915.3 kg
30,678 lb

Total weight with carbon fiber boom (empty solution tank)

14,510 kg
31,989 lb
*Includes: 36.6-m (120-ft) carbon fiber boom, pressure recirculation, ExactApply, and 50.8-cm (20-in.) spacing. Weight will vary depending on all options.

Total weight (empty solution tank)

15,125 kg
33,197 lb
*Includes: 36.6-m (120-ft) steel boom, pressure recirculation, ExactApply, and 38.1-cm (15-in.) spacing. Weight will vary depending on all options.

Air compressor

Standard: Onboard air

Foam marker capacity

Air injection foamer: 5.7 L
1.5 gal.

Date collected

1 March 2021
