Belts-other

Number
Six
Width
17.8 cm
7 in.
Texture
Diamond Tread friction surface belts
DiamondTough, triple-weave, single-ply belts

Density control

Hydraulic

Bale size indication

Not available from factory, available as dealer-installed options

Width

Inside
117 cm
46 in.
Flare
141 cm
56 in.

Bars

Four

Number of teeth

72

Tooth spacing

6 cm
2.6 in.

Lift control

Adjustable height control

Gauge wheels

Semi-pneumatic

Stripper diameter

25.4 cm
10 in.

Control

Automatic to preset to bale size

Type

Standard
Electric

Twine arms

Two

Twine ball capacity

Four

Gate closed

Symbol on monitor

Bale size

Mechanical

Near full bale

Audible alert

Full bale

Audible alert

Twine arm position Indicator

Mechanical

Auto wrap

Activates when bale reaches preset size

Oversize bale

Yes, audible and mechanical alerts

Standard

11 L - 14

Drive protection

Shear-bolt

PTO speed

540 rpm

Type

Constant-velocity (CV)

PTO lockback collar on tractor hookup

No

PTO 60-degree free rotation

No

Minimum PTO

Dry Hay and Silage - 42 kW
55 hp

Hydraulic SCV valves

One tractor selective control valve (SCV) is required when baler is equipped with electric twine wrap.
Two tractor SCVs are required when baler is equipped with hydraulic twine wrap.
Three tractor SCVs are required when baler is equipped with hydraulic twine wrap and a hydraulic pickup lift.

Date collected

22-Aug-2023
