Maximum lift height

3150 mm
124 in.

Lift capacity at full height

Measured at pivot
1463 kg
3225 lb

Boom breakout force

Measured at pivot
1975 kg
4354 lb

Bucket rollback force capacity

At ground-level line
3369 kg
7427 lb

Clearance at full height - bucket dumped

2187 mm
86 in.

Dump angle, degrees

57 degree (angle)

Rollback angle, degrees

42 degree (angle)

Model

5E 3-Cyl FT4 (5045E, 5050E, 5055E, 5060E, 5065E, 5067E, 5075E)

Front tire

9.5 - 24

Wheelbase

80.7 in (205 cm)

Pump capacity

11.4 gpm
(43.2 lpm)

Rated pressure

2828 psi

Leveling configuration

Non-Self Leveling (NSL)

Bucket used

General Purpose
1850 mm
73 in.

Bucket weight

220 kg
458 lb

Lift capacity at full height

Measured at pivot
1463 kg
3225 lb
Measured at 800 mm ahead of pivot
896 kg
1975 lb

Lift capacity at 59 in. (1500 mm)

Measured at pivot
1715 kg
3780 lb
Measured at 800 mm ahead of pivot
1208 kg
2663 lb

Boom breakout force

Measured at pivot
1975 kg
4354 lb
Measured at 800 mm ahead of pivot
1295 kg
2855 lb

Bucket rollback force capacity

At maximum height
2030 kg
4475 lb
At 59-in. (1500-mm) lift height
3388 kg
7469 lb
At ground-level line
3369 kg
7427 lb

Dimensions

Maximum lift height
3150 mm
124 in.
At full height - bucket level
2964 mm
116 in.
At full height - bucket dumped
2187 mm
86 in.

Overall length

4207 mm
165 in.

Digging depth

122 mm
4.8 in.

Reach

At maximum height
486 mm
19 in.
At ground level - bucket level
2157 mm
85 in.

Bucket angle

Dump angle, degrees
57 degree (angle)
Rollback angle, degrees
44 degree (angle)
Dump angle, ground
149 degree (angle)

Cycle times

Loader raise, seconds
2.8 seconds
Loader lower, seconds
2 seconds
Bucket dump, seconds
4.2 seconds
Bucket rollback, seconds
3 seconds
