Belts-other

Number
Eight
Width
17.8 cm
7 in.
Texture
Diamond Tread friction surface belts
DiamondTough, triple-weave, single-ply belts

Density control

Hydraulic

Bale size indication

Electronic display on monitor

Width

Inside
156 cm
62 in.
Flare
180 cm
71 in.

Bars

Four

Number of teeth

96

Tooth spacing

6 cm
2.6 in.

Lift control

Adjustable height control

Gauge wheels

Semi-pneumatic

Stripper diameter

25.4 cm
10 in.

Width

Inside
196 cm
77 in.
Flare
221 cm
87 in.

Number of regular teeth

120

Number of mega teeth

Eight

Gauge wheels

Semi-pneumatic

Type

MegaWide High Capacity and Cutting (HC

Control

Automatic to preset to bale size

Type

Standard
Electric

Twine arms

Two

Twine ball capacity

Six

Gate closed

Symbol monitor

Bale forming

G5e

Bale size

Mechanical and digital

Near full bale

Audible, adjustable alert

Full bale

Audible, adjustable alert

Twine arm position Indicator

Mechanical

Auto wrap

Activates when bale reaches preset size

Oversize bale

Yes, audible and mechanical alerts

Standard

Dry and Silage - high-flotation 14 L - 16.1, 8 PR

Optional

With MegaWide Plus or HC

Drive protection

Slip clutch

PTO speed

540 or 1,000 rpm

Type

Constant-velocity (CV)

PTO lockback collar on tractor hookup

Yes

PTO 60-degree free rotation

Yes

Minimum PTO

Dry Hay and Silage - 42 kW
55 hp
HC - 63 kW
85 hp

Hydraulic SCV valves

One tractor selective control valve (SCV) is required when baler is equipped with electric twine wrap.
Two tractor SCVs are required when baler is equipped with hydraulic twine wrap.
Three tractor SCVs are required when baler is equipped with hydraulic twine wrap and a hydraulic pickup lift.

Date collected

22-Aug-2023
