Front

Fully independent dual A-Arm with adjustable coils; 8 inches (203 mm) of travel

Rear

Fully independent dual A-Arm with adjustable coils and sway bar; 9 inches (228.6 mm) of travel

Type

Front/rear hydraulic disc with twin piston front calipers

Park brake

Driveline, internal wet multi-disc, hand operated

Front

25x9-12 Terrahawk AT, 27x9-R14 Maxxis Big Horn Radials (on Alloy Rims), or Maxxis Big Horn Radials (on Steel Rims)

Rear

25x11-12 Terrahawk AT, 27x11-R14 Maxxis Big Horn Radials (on Alloy Rims), or Maxxis Big Horn Radials (on Steel Rims)

Wheelbase

79 in.
2007 mm

Dry weight

1775 lb
805 kg

Length

118 in.
2992 mm

Width

62 in.
1571 mm

Height

75 in.
1903 mm

Tread centers

51.4 in.
1305 mm

Ground clearance

11 in.
280 mm

Fuel capacity

7.3 U.S. gal.
27.6 L

Cargo box dimensions

1143 x 304.8 x 1320 mm
45 x 12 x 52 in.

Cargo box capacity (weight)

454 kg
1000 lb

Payload capacity

1400 lb
635 kg

Towing capacity

1500 lb
680 kg

Hitch

Standard 2-in. receiver

Color

Green/Yellow, Camouflage, Olive and Black

Power steering

Standard

Battery / Alternator / Power port

480 CCA
85 amp @ 6000 rpm, regulated, 1020 watts

Instrumentation

Digital Display (system diagnostic light, speed, rpm, 4WD indicator, fuel level, coolant temperature, hour meter, miles, park brake light)

Storage

2 Cup Holders, Under Hood, Glovebox

Seating

Bench (Available Bucket Seats)
