Charge system

At 3,600 rpm 30A

Battery voltage

12 V

Cold cranking amp

300 CCA

Hour meter

Display panel including hour meter, fuel level, engine speed, system voltage, low engine oil pressure indicator, starting interlock indicators (PTO, operator presence, park brake), caution warning, stop warning, and on-board diagnostics

Operator presence starting system

Yes

Transmission

Tuff Torq TZT13 IHT

Hydraulic pumps

0.79 cu in.
13 cc

Wheel motors

13 cu in.
213 cc

Travel speed

Speed range
0-12 mph
0-19.3 km/h
Forward
Infinite, 0-12 mph
Infinite, 0-19.3 km/h
Reverse
Infinite, 0-6 mph
Infinite, 0-9.7 km/h

Speed and direction control

Twin hand-controlled levers

Hydraulic capacity

6.0 U.S qt
5.7 L

Hydraulic oil cooler

Two 8.5 in. (22 cm) fans

Filter

Two internal and replaceable

Warranty

36 months or 1500 hours, whichever comes first.
First 24 months, no hour limitation.

Drive wheels

24x12-12 pneumatic
24x12N12 Tweel

Load rating

4 PR

Dynamic braking

Dual hand-controlled levers

Park brake

Internal wet disk

Park brake actuation

Hand lever

Type

Electro-magnetic with brake, 225 lb-ft
305 Nm

Drive

V-belt

Size

60-in. (152-cm) 7Iron™ PRO side-discharge

Deck construction

7-Iron™ PRO: one-piece forged steel

Deck thickness

7 gauge
0.180 in.
4.6 mm

Discharge

Side

Height-of-cut range

Increments
0.25 in.
0.64 cm
1.5-5 in.
3.8-12.7 cm

Cutting width

60-in. (152-cm) 7Iron™ PRO side-discharge

Thickness

0.25 in.
0.64 cm

Blade tip speed

Approximately 18,000 fpm
5486 m/min

Number

Three

Caster wheel type

Flat free

Caster wheels

13x5-6

Front anti-scalp rollers

RH, center, LH

Length

Foot platform up, 70 in.
183 cm
Foot platform down, 74.75 in.
190 cm

Width

With chute down, 74 in.
188 cm

Height

49 in.
124 cm

Weight

1165 lb
528 kg

Date collected

28-Aug-2023
