Charge system

30 amp

Battery voltage

12 V

Cold cranking amp

300 amp

Hour meter

Standard, digital

Operator presence starting system

Brake-N-Go (hand)

Transmission

Hydrostatic

Wheel motors

Tuff Torq heavy-duty integrated piston wheel motor

Travel speed

Speed range
0-12 mph
0-19.3 km/h
Forward
0-12 mph
0-19.3 km/h
Reverse
0-4.5 mph
0-7.2 km/h

Speed and direction control

Twin levers

Hydraulic capacity

5.9 U.S. qt
5.6 L

Filter

Internal, replaceable

Warranty

36 months or 1200 hours, whichever comes first
First 24 months, no hour limitation

Drive wheels

24x12-12

Load rating

4 PR

Dynamic braking

Twin levers

Park brake

Internal wet disk integrated in the transmission

Park brake actuation

Hand brake

Type

Electro-magnetic, 225 lb-ft
305 Nm

Drive

V-belt

Size

60-in. (152-cm) 7Iron™ PRO side-discharge
72-in. (183-cm) 7Iron™ PRO side-discharge
60-in. (152-cm) 7Iron™ PRO Mulch On Demand™
60-in. (152-cm) FastBack™ PRO rear-discharge
72-in. (183-cm) FastBack™ PRO rear-discharge

Deck construction

7-Iron™ PRO: 7-gauge, 0.179-in. (4.6-mm) one-piece forged steel
FastBack™ PRO: 7-gauge, 0.179-in. (4.6-mm) fabricated steel

Height-of-cut range

Increments
0.25 in.
0.64 cm
1-5.5 in.
2.54-14 cm

Cutting width

60, 72 in.
152, 183 cm

Length

Varies by deck size

Thickness

0.25 in.
0.64 cm

Blade tip speed

7Iron PRO: Approximately 18,500 fpm
60-in. (152-cm) FastBack: Approximately 16,500 fpm
72-in. (183-cm) FastBack: Approximately 18,000 fpm

Number

Three

Caster wheel type

Flat free

Caster wheels

13x6.5-6

Front anti-scalp rollers

RH, center, LH

Rear anti-scalp rollers

Standard

Length

84 in.
213 cm

Width

With chute down, 74, 86 in.
188, 218 cm
Rear discharge, 63.5, 75.8 in.
161.3, 192.5 cm

Height

With ROPS up, 73 in.
185 cm
With ROPS down, 47 in.
119 cm

Weight

1,304 to 1,412 lb
591 to 640 kg

Date collected

1-Aug-24

Rollover protective structure (ROPS)

Yes

Slope operating limit

20 degrees (10 degrees with material collection system installed)
