BL9B Snow/Utility Blade featured on 333G Compact Track Loader

Overview

Each blade will have the capability of being rigid side to side or float (5 degrees) from side-to-side. The side-to-side float allows for easier operation and allowances for uneven surfaces.

Figure A. : Oblong Pin – Makes the blade a rigid blade side-to-side
Figure B. : Round Pin  –Allows blade to float five degrees side-to-side

Hydraulically-actuated BL8B Snow/Utility Blade

BL9B featured on the 333G

Overview

Blade angles hydraulically 30 degrees, right or left enabling easy snow placement via in-cab controls.

BL9B Snow/Utility Blade featured on 333G Compact Track Loader

Overview

Four trip springs help protect the vehicle from sudden impacts with obstacles when blading snow. Trip springs can be locked out for light grading and dirt work.

BL9B Snow/Utility Blade on the 324L High-Lift

Easily adjustable skid shoes

Overview

BL-Series Snow/Utility Blades have easily adjustable skid shoes that can be adjusted based on the surface beneath the snow. Adjusting the skid shoes can be done without tools by removing the quick-lock pin and positioning the adjustment bushings to either raise or lower the skid shoe.
