Engine

Rated power
384 kW
515 hp
Power boost
24.6 kW
33 hp
John Deere JD14P 13.6 L
830 cu in.

Module shape

Round/cylindrical

Module dimensions

Diameter up to 244 cm
96 in.
Width up to 239 cm
94 in.

Module weight

1,995-2,449 kg
4,400-5,400 lb

Configurations

Number of rows
Eight or twelve
SH8R, SH12R, SH12F

On-board cleaner

Type
Three drum
Yes

Engine

Emission level
Stage IIIA and Final Tier 4 (FT4)
Rated speed
1900 rpm
Rated power
384 kW
515 hp
Maximum power
422 kW
566 hp
Power boost
24.6 kW
33 hp
Displacement
13.6 L
830 cu in.
Cylinders
Six
Turbocharged/aftercooled
Yes
Alternator
Single 330 amp
John Deere JD14P 13.6 L
830 cu in.

Cooling system

Variable pitch reversible fan
Yes
Ground-level access to coolers
Yes

Fuel system

Type
Electronic unit direct injection
Governor
Electronic
On-board diagnostics
Yes

Transmission

Gears
Two range
Field mode 1 (4WD)
0 to 8.1 km/h
0 to 5 mph
Field mode 2 (4WD)
0 to 14.5 km/h
0 to 9 mph
Field transport mode 3 (4WD)
0 to 14.5 km/h
0 to 9 mph
Road transport mode 4 (4WD)
0 to 32.2 km/h
0 to 20 mph
ProDrive™ automatic-shift (AST)

Hydrostatic system

Type
Hydrostatic/mechanical drive
Wet, multiple disc

Tires

Standard drive tire
520/85R42 (20.8R42) R1W
Dual wheels
Yes
Dual tire size (standard)
520/85R42 (20.8R42) R1W
Standard steering tire
IF580/80R34 R1W

Rear wheel drive

Yes (full time)

Module Shape

Round/cylindrical

Module Dimensions

Diameter up to 244 cm
96 in.
Width up to 239 cm
94 in.

Module Weight

1,995.8-2,449.4 kg
4,400-5,400 lb

Unload on-the-go

Yes

Wrap system carrying capacity

120 portions
