dh51_xf

John Deere DH51 Series

Key Features

Adjustable disk blade scrapers increase productivity
Notched or smooth disk blades available in two sizes
Durable clevis hitch
Oil bath tapered roller bearings minimize maintenance

Call Today 866-475-0145

I'm Interested Call

Transport

Width	4 m 13 ft
Ground clearance with base blades	20.3 cm 8 in.
Wheel hub bearings	Dual Tapered Roller Bearings

Working

Approximate working width	3.7 m 12 ft
Maximum penetration	22.9 cm 9 in.

Weight

Net	2,887.1 kg 6,365 lb
Weight per disk blade	115.7 kg 235 lb

SHOW MORE SHOW LESS

Request Information
DH51 Series Offset Disks

First Name Last Name Email Address * Zip Code * Promo * Phone Number Questions or Comments

Compare {{items.length}}/4

✕ {{ item.title }}

You're almost there, select at least one more to compare!

Compare All

Recommended PTO hp range	96-118 kW 129-159 hp
Recommended drawbar hp range	82-100.7 kW 110-135 hp

Type	Single Offset Rigid
Duty	General Purpose
Tube size	12.7x12.7x0.95 cm 5x5x0.375 in.

Spacing	26.7 cm 10.5 in.
Quantity	27
Type	Notched (front) Notched (rear) Standard Smooth (front) Smooth (rear) Optional Notched (front) Smooth (rear) Optional
Blade concavity	Standard high, Optional low

Blade option one	660x7.9 mm 26x0.312 in.
Blade option two	711x7.9 mm 28x0.312 in.

Front angle	2 Positions
Rear angle	2 Positions
Axle size	4.1 cm 1.625 in. or 5.4 cm 2.125 in.
Axle material	Round Heat Treated Alloy Steel Threaded on Both Ends
Bearing type	Oil Bath Tapered Roller
Bearing wear plates	Standard
Bearing standards	Welded, Reinforced
Scrapers	Adjustable

Type	Implement - Quantity of 4
Size	9.5L x 15-in. 8 ply
Wheel hub type	6 Bolt

Markings	SMV
Safety tow chain	Yes
Lights	Yes

Disk blades
Frame

John Deere DH51 Series

Key Features

Call Today 866-475-0145

Transport

Width

Ground clearance with base blades

Wheel hub bearings

Working

Approximate working width

Maximum penetration

Weight

Net

Weight per disk blade

Tractor requirements

Recommended PTO hp range

Recommended drawbar hp range

Frame

Type

Duty

Tube size

Hitch

Front hitch type

Disk blades

Spacing

Quantity

Type

Blade concavity

Available blade sizes

Blade option one

Blade option two

Disk gangs

Front angle

Rear angle

Axle size

Axle material

Bearing type

Bearing wear plates

Bearing standards

Scrapers

Lighting and safety

Markings

Safety tow chain

Lights

Tires

Type

Size

Wheel hub type

Set-up time

Labor hours

Warranty

Time period

Key Specs
