dh55_xf

John Deere DH55 Series

Key Features

Adjustable disk blade scrapers
Oil bath tapered roller bearings minimize maintenance
Working widths from 10-ft. to 13.75-ft.

Call Today 866-475-0145

I'm Interested Call

Transport

Width	3.7 m 12 ft
Wheel hub bearings	Dual tapered roller bearings

Working

Approximate working width

3.4 m
11 ft

Weight

Net	5443.1 kg 12000 lb
Weight per disk blade	272.2 kg 600 lb

SHOW MORE SHOW LESS

Request Information
DH55 Series Offset Disks

First Name Last Name Email Address * Zip Code * Promo * Phone Number Questions or Comments

Compare {{items.length}}/4

✕ {{ item.title }}

You're almost there, select at least one more to compare!

Compare All

Type	Single offset rigid
Duty	Heavy
Tube size	20.3x20.3x1.3 cm 8x8x0.5 in.

Spacing	35.6 cm 14 in.
Quantity	20
Type	Notched (front) Notched (rear) Standard

Front angle	3 positions
Rear angle	3 positions
Axle size	6.4 cm 2.5 in.
Axle material	Round heat treated alloy steel threaded on both ends
Bearing type	Oil bath tapered roller
Bearing wear plates	Standard
Bearing standards	Welded, Reinforced
Scrapers	Adjustable

Markings	SMV
Safety tow chain	Yes
Lights	Yes

Type	2 - Radial industrial
Size	385/65R22.5
Wheel hub type	5-Spoke dayton hubs

John Deere DH55 Series

Key Features

Call Today 866-475-0145

Transport

Width

Wheel hub bearings

Working

Approximate working width

Weight

Net

Weight per disk blade

Tractor requirements

Recommended drawbar hp range

Frame

Type

Duty

Tube size

Hitch

Front hitch type

Disk blades

Spacing

Quantity

Type

Available blade sizes

Blade option one

Disk gangs

Front angle

Rear angle

Axle size

Axle material

Bearing type

Bearing wear plates

Bearing standards

Scrapers

Lighting and safety

Markings

Safety tow chain

Lights

Tires

Type

Size

Wheel hub type

Set-up time

Labor hours

Warranty

Time period

Request InformationDH55 Series Offset Disks

Request Information
DH55 Series Offset Disks
