Name: John Deere STS10
Brand: John Deere
SKU: st10sxf

Key Specs

Engine	Peak rated power 208 kW 280 hp
Solution system - Capacity	3700 L 1000 gal.
Rinse tank capacity	380 L 100 gal.
Boom length options/Material	18/24/27, 18/30, or 36/40 m 60/80/90, 60/100, or 120/132 ft
Spray speed range	0.8 to 32 km/h 0.5 to 20 mph
Transport speed, maximum	56 km/h 35 mph
Suspension	Independent air-ride
Crop clearance with standard tires	183 cm 72 in.
Total weight with widest boom	12,147 kg 26,780 lb

Engine

Peak rated power	208 kW 280 hp
Emissions	Final Tier 4 (FT4)
Number of cylinders	Six
Displacement	6.8 L 415 cu in.
Alternator	200 amp
Fuel tank capacity	510 L 135 gal.
Diesel exhaust fluid (DEF) tank capacity	37.9 L 10 gal.

Solution system

Capacity	3700 L 1000 gal.
Tank material	Poly, stainless steel
Rinse tank capacity	380 L 100 gal.
Quick fill size	7.6 cm 3 in.
Automatic section control	Optional
Solution system control	John Deere
Fill location	Front standard Side/rear optional
Chemical injection method	Raven Sidekick - optional
Chemical eductor	Optional
Chemical eductor capacity (size)	30.3 L 8 gal.
Flow meter size	5.8 cm 2 in.
Pressure strainer	50 mesh
Boom strainer	Standard 80 mesh

Boom

Boom length options	18/24/27, 18/30, or 36/40 m 60/80/90, 60/100, or 120/132 ft
Automatic boom height	NORAC
Plumbing material	Stainless steel
Ground height adjustment	46 to 264 cm 18 to 104 in.
Breakaway width	For 27-m (90-ft) booms - 3 m 10 ft For 30-m (100-ft) booms - 3.8 m 12.5 ft For 36-m (120-ft) booms - 4.6 m 15 ft
Boom sections	7 or 9 sections on booms - 27/36 m 90/120 ft

Drivetrain

Type	Hydrostatic
Drive	Full-time four-wheel drive (4WD)
Shifting	Infinitely variable
Hydraulic reservoir capacity	190 L 50 gal.
Spray speed range	0.8 to 32 km/h 0.5 to 20 mph
Transport speed, maximum	56 km/h 35 mph

Chassis

Dry compatible	No
Suspension	Independent air-ride
Crop clearance with standard tires	183 cm 72 in.
Front tires	380/85R46, 320/90R50, or 320/105R54
Rear tires	380/85R46, 320/90R50, or 320/105R54
Flotation tires	LSW 680/55R42
Hydraulic tread adjust	Optional
Wheel tread spacing	305 to 386 cm 120 to 152 in.
Wheel base	356 cm 140 in.
Turning radius	5.6 m 18.5 ft
Parking brake	Integrated in final drives
Primary brakes	Drive system dynamic braking
Ladder raise/lower	Hydraulic
Total weight with 90-ft boom	12,265 kg 27,040 lb
Total weight with 120-ft boom	12,147 kg 26,780 lb

Options

Air compressor	Onboard air
Foam marker capacity	11.35 L 3 gal.

Additional information

Date collected

08-May-2018
