Boom length options

Hybrid steel and aluminum: 18/27, 18/30, 18/36, or 21/40 m
60/90, 60/100, 60/120, or 70/132 ft

Automatic boom height

NORAC® UC7™ with Active Wing Roll (AWR)

Plumbing material

Stainless steel

Ground height adjustment

58 to 272 cm 23 to 107 in.

Breakaway width

For 27-m (90-ft) booms: 1.5 m 5 ft
For 18/30 or 18/36 (60/100 or 60/120 ft): 3 m 10 ft
For 40-m (132-ft) booms: 3.3 m 11 ft

Boom sections

On 27-m (90-ft) boom: 7 sections
On 30-, 36-, and 40-m (100-, 120-, and 132-ft) booms: 9 sections m
(100, 120 and 132 ft)

Type

CommandDrive™

Drive

Full-time four-wheel drive (4WD)

Shifting

Infinitely variable - Operator programmable

Hydraulic reservoir capacity

113.5 L
30 gal.

Spray speed range

0.8 to 40 km/h
0.5 to 25 mph

Transport speed, maximum

56 km/h
35 mph

Dry compatible

Montag® Fortifier

Suspension

Independent air-ride

Crop clearance with standard tires

188 cm
74 in.

Front tires

VF320/105R54, VF380/90R54, VF380/105R50, VF420/95R50, VF480/80R50

Rear tires

VF320/105R54, VF380/90R54, VF380/105R50, VF420/95R50, VF480/80R50

Flotation tires

VF480/80R50, VF 620/70R46, IF710/65R46

Hydraulic tread adjust

Standard

Wheel tread spacing

305 to 406 cm
120 to 160 in.

Wheel base

386 cm
152 in.

Turning radius

With all-wheel steer (AWS) on: 5.3 m 17.3 ft
With AWS off (center of outside tire): 7.8 m 25.6 ft

Parking brake

Integrated in final drives

Primary brakes

Drive system dynamic braking

Ladder raise/lower

Hydraulic

Total weight with 90-ft boom

14,333.5 kg
31,600 lb

Total weight with 100-ft boom

14,288 kg
31,500 lb

Air compressor

Onboard air

Date collected

1 March 2021
