Name: John Deere STS14
Brand: John Deere
SKU: st14sxf

Key Specs

Engine	Peak rated power 224 kW 300 hp
Solution system - Capacity	5000 L 1400 gal.
Rinse tank capacity	378.5 L 100 gal.
Boom length options/Material	18/24/27, 18/30, or 36/40 m 60/80/90, 60/100, or 120/132 ft
Spray speed range	0.8 to 32 km/h 0.5 to 20 mph
Transport speed, maximum	56 km/h 35 mph
Suspension	Independent air-ride
Crop clearance with standard tires	183 cm 72 in.
Total weight with widest boom	13,156 kg 29,006 lb

Engine

Make	John Deere
Peak rated power	224 kW 300 hp
Emissions	Final Tier 4 (FT4)
Number of cylinders	Six
Displacement	9 L 548 cu in.
Alternator	240 amp
Fuel tank capacity	510 L 135 gal.
Diesel exhaust fluid (DEF) tank capacity	37.9 L 10 gal.

Solution system

Capacity	5000 L 1400 gal.
Tank material	Stainless steel
Rinse tank capacity	378.5 L 100 gal.
Quick fill size	7.6 cm 3 in.
Automatic section control	Optional
Solution system control	John Deere
Fill location	Front standard Side/rear optional
Chemical injection method	Raven Sidekick - optional
Chemical eductor	Optional
Chemical eductor capacity (size)	30 L 8 gal.
Flow meter size	5.8 cm 2 in.
Pressure strainer	50 mesh
Boom strainer	Standard 80 mesh

Boom

Boom length options	18/24/27, 18/30, or 36/40 m 60/80/90, 60/100, or 120/132 ft
Plumbing material	Stainless steel
Ground height adjustment	46 to 264 cm 18 to 104 in.
Breakaway width	For 27-m (90-ft) booms - 3 m 10 ft For 30-m (100-ft) booms - 3.8 m 12.5 ft For 36-m (120-ft) booms - 4.6 m 15 ft
Boom sections	7 or 9 sections on booms - 27/36 m 90/120 ft

Drivetrain

Type	Hydrostatic
Drive	Full-time four-wheel drive (4WD)
Shifting	Infinitely variable
Hydraulic reservoir capacity	190 L 50 gal.
Spray speed range	0.8 to 32 km/h 0.5 to 20 mph
Transport speed, maximum	56 km/h 35 mph

Chassis

Dry compatible	No
Suspension	Independent air-ride
Crop clearance with standard tires	183 cm 72 in.
Front tires	380/85R46, 320/90R50, or 320/105R54
Rear tires	380/85R46, 320/90R50, or 320/105R54
Flotation tires	LSW 680/55R42
Hydraulic tread adjust	Optional
Wheel tread spacing	305 to 386 cm 120 to 152 in.
Wheel base	422 cm 166 in.
Turning radius	7 m 23 ft
Parking brake	Integrated in final drives
Primary brakes	Drive system dynamic braking
Ladder raise/lower	Hydraulic
Total weight with 90-ft boom	13,274 kg 29,266 lb
Total weight with 120-ft boom	13,156 kg 29,006 lb

Options

Air compressor	Onboard air
Foam marker capacity	12 L 3 gal.

Additional information

Date collected

14-Jun-2017
